Cover: UL94V-0, PBT, red, black, blue
Push button: UL94V-0, PBT, white
Terminal: copper alloy plating
Mechanical characteristics
Operation: 0.2kgf Max
Push button stroke: 2.0mm
Operating temperature: -20 C to 70 º Cº
Storage temperature: -40 C to 85 º Cº
Electrical characteristics
Electrical life: each switch in the voltage and current of 25mA 24VDC under test, and struck 2000 times
The switch doesn't often switch rated current: 100mA, voltage 50VDC
Switch switch current rating: 25mA, voltage 24VDC
Contact resistance: initial value maximum 50m
Insulation resistance: the minimum 100m, 500VDC
Compressive strength: 500VAC/1 minutes
International: maximum 5PF pole capacitor
Loop: single contact single selection
Welding and cleaning process
For best results, please click the following requirements operation:
In all the operation process, please make sure that the switch is in the " OFF" position.
Wave soldering: recommended soldering temperature at 500° F (260 °) for up to 5 seconds.
Hand soldering: use 30 watt soldering iron, temperature control at 608° F (320 °), welding time is about 2 seconds。
