Product details

Product Description:
Electrical
Standard
UL
IEC
Rated voltage
300V
250V
Rated current
8A
7A
Wire range
28-16AWG
0.5-1.5mm2
Withstanding voltage
AC2000V/1Min

Mechanical
Torque
0.2Nm(1.7Lb-In.)
Ambient temperature
-40°C~+105°C
Strip length
7mm

Dimensions
Pitch
3.5mm(.138") 3.81mm(.150")
Poles
2P-20P

Material
Housing
PA66,UL94V-0
Screws
M2,steel,Cr3+ Zn plated
Contact
Phosphor bronze
Cage
Brass,Ni plated

412×354
