Location : Home - Products

Back

Product details

Product Description:
Electrical
Standard
UL
IEC
Rated voltage
300V
250V
Rated current
20A
20A
Wire range
26-12AWG
0.5-2.5mm2
Withstanding voltage
AC2000V/1Min

Mechanical
Torque
0.5Nm(4.4Lb-In.)
Ambient temperature
-40°C~+105°C
Strip length
7mm

Dimensions
Pitch
5.0mm(.197"),5.08mm(.200")
Poles
2P,3P-24P

Material
Housing
PA66,UL94V-0
Screws
M3,steel,Cr3+ Zn plated
Pin header
Brass,Tin plated
Cage
Brass,Ni plated
